Complete Line with the Following Components:
Coil Car
20,000#, 24” Hydraulic Uncoiler
Peeler Hold down
Powered Flattener
26” Wide
Entry & Exit Pinch Rolls
150 Ton Alpha Prenotch Press
BED SIZE: 52.5" x 52.5"
DISTANCE BETWEEN POSTS: 24.25" APPROX.
SPEED: 300 FPM
STROKE: 8"
STROKES PER MINUTE: 30 PPM
PASS LINE HEIGHT: 57" FROM FLOOR TO TOP OF BED
HAND OF OPERATION: RH
20 HP RELIANCE AC MAIN MOTOR 1760 RPM, 220/440 V, 60 HZ.
MODEL SMXIV24H Servo Max HIGH CAPACITY ELECTRONIC ROLL FEED (NEW)
Maximum stock width .......24"
Capacity in mild steel at full width ...0.187"
Maximum feed length ........... 999.999"
Roll position accuracy ....... +/- 0.002”
Roll diameters .........(2). 4.00"
Roll widths .upper ..25", lower .....29"
Pass line height from baseplate .......7.50"
Feed dimensions.......44" w x 44" dp x 28" h
Control dimensions ……20" w x 13" dp x 42" h
Voltage .460/3/60 in a WYE configuration
Control platform ...B&R
14 STAND X 3.5" X 24" TISHKEN MODEL #14-HXM-3-1/2 HEAVY DUTY ROLLFORMER
NUMBER OF PASSES .......... 14 (8 & 6)
ARBOR DIAMETER ............ 3-1/2"
MAX ROLL SPACE ......... 24"
VERTICAL ADJUSTMENT ....... 8" TO 11"
HORIZONTAL CENTERS ........ 18"
BASE TO BOTTOM SHAFT ...... 10"
DIRECTION OF TRAVEL ....... R TO L
ENTRY EDGE GUIDES ......... YES
EXIT STRAIGTENING HEAD .... YES
CONTROL STATION ........... YES
MOTOR ..................... 40 HP
AMS MP350H LENGTH CONTROLLER (NEW)
Model MP Series Controller
Model NK-1 Noise Kit
MP300 Open Loop Manual, V13
Model 3812X-10 Power Cable
4348-10 Auxiliary Cable
Model N256 Encoder
Encoder Cable 3148-10
Model KMW-12 Knurled Wheel
Encoder Bracket Kit w/ Screws
BRKT-1 Encoder Bracket
80 TON BRADBURY CUTOFF PRESS
AGE ............................. 1996
CAPACITY ........................ 80 TON
STROKE .......................... 1"
SHUT HEIGHT ..................... 26-1/2"
SPM ............................. 55 (I)
DISTANCE BETWEEN POST GUIDES .... 92" X 51"
PASS LINE HEIGHT ................ 41"
AIR CLUTCH ...................... YES
TOOLING:
14 pr D2, Rolls (existing )
Inboard & Outboard Spacers
Bronze Straightener
Pre notch Die
Slugless Cutoff Die
