Equipped With
General Specifications:
Minimum Size of Ingots Milled: 1000mm L x 750mm W x 180mm Thick
Maximum Size of Ingots Milled: 3000mm L x 2000mm W x 350mm Thick
Size of Table Working Surface: 6600mm x 2100mm
Maximum Table Travel: 5820mm
Number of Table Feed Steps: Infinitely Variable
Range of Table Feeds: 800mm-4000mm/min
Number of Spindles: One Horizontal
Spindle Speed: 250 RPM
Maximum Spindle Travel: 45mm
Diameter of Milling Cutter: 2300mm
Maximum Slip-Way Travel: 170mm
Working Space Dimensions:
Distance Center Line of Spindle to Top of Table: 1320mm
Distance Center Line of Holding Fixture to Axis of Spindle: 4500mm
Distance Center Line of Ingot Loading and Turning Device to Spindle Axis: 4500mm
Main Drive: 250kw
Table Feed and Rapid Traverse Drive: 25kw
