Equipped With
General Specifications:
Max Coil Weight: 30 Tons
Width Range: 10"-60" (250mm-1600mm)
Thickness Range: .039"-.276" (1mm-7mm)
Coil OD Range: 32"-82" (800mm-2100mm)
Entry Coil ID: 20", 24", 30", 32" (508mm, 610mm, 760mm, 810mm)
Exit Coil ID: 24" (610mm)
Max Line Speed: 320ft/min (100m/min)
Complete with the Following Components:
Entry Coil Car
Double Mandrel Uncoiler
Peeler Table and Hold Down Roll
Flattener
Entry Crop Shear
Slitter Head with Four Arm Tooling Capstan
Scrap Choppers
Looping Pit
Tension Stand
Rotary Drag Board Tension Stand
Exit Crop Shear
Recoiler with Overarm Separator
Exit Coil Car
Exit Four Arm Turnstile
Siemens PLC, Siemens and Control Techniques Drives
