Manufacturer: Dimeco
Year: 2011
Line Direction: Right to Left
Speed: 45mpm
Tooled to Produce Rounds, Square, Rectangular and Octagon
Round: 5"
Square: 4" x 4"
Solar Torque Octagon Tube : 5.20"
Complete Mill with the Following Components:
Floor Type Coil Car
Mandrel Uncoiler (2011)
Make.- DIMECO (Spain)
Capacity.- 6.5mT
Electronics.- Siemens
Shear End Welder (2011)
Make.- DIMECO (Spain)
Electronics.- Siemens
Horizontal Accumulator
Make.- S.V.M ( Italy)
Capacity.- 12mT
Electronics.- Allen-Bradley
Forming / Fin Stands (2011)
Make.- DIMECO (Spain)
Capacity.- 2mm-3.0mm
Electronics.- Allen-Bradley
Shaft Diameter 3.1"
Motor Data:
• SERVO MOTOR
• 61.6AMP
• 600VAC
• 1500//6000MIN-1
• 240NM BRAKE
• IP65
4 Roll Weld Box
300KW High Frequency Solid State Welder
Make.- BAODING SANZHENG ELECTRICAL EQUIPMENTCO.,LTD.
OD Scarfing Unit
Zinc Re-Metalizing System (Year 2023)
Make.- THERMACH (USA)
Capacity.- 45m/min (20microns coating)
Dust Collector System
Make.- ACT ( USA)
Cooling Tunnel
3 Stand Sizing Section
Make.- DIMECO (Spain)
Capacity.- 2mm Thickness
Electronics.- Allen Bradley
Motor Data:
• SERVO MOTOR
• 61.6AMP
• 600VAC
• 1500//6000MIN-1
• 240NM BRAKE
• IP65
Single Sided Turks Head
Cold Cut Off Saw
Make.- CONTOR (China)
Capacity.- 127mm, 45m/min
Electronics.- YASKAWA
Tube Packaging System
Capacity.- Semi-Manual
Electronics.- Schneider
Complete with Controls, Hydraulics, Electrics, Manuals
Installed and Running
Video Available Upon Request
