Shaft Diameter: 3.15" (80mm)
Welding Type: TIG
Size Range: 2.00”-4.50” (50.8mm-114mm)
Wall Thickness: .049”-.120” (1.24mm-3mm)
Max Speed: 13ft/min
Includes the Following Components:
Oto Mills Double Mandrel Uncoiler
Shear and End Welder
Pit Type Accumulator
Entry Pinch Rolls
Two Sets of Edge Guides
Five Forming Stands
Three Idle Passes
Three Finn Stands
Weld Box with Two Shoes
Le. Di. Co. Tricathode System
Idle Rolls
Stand
Idle Rolls
Two Polishers
Four Sizing Stands
Turks Head
Allen Bradley PLC and Drives
