Equipped With
General Specifications:
Year 2004
Tube Diameter Range: .413"-2" (10.5mm-60.5mm)
Wall Thickness Range: .031"-.078" (.8mm-2mm)
Line Speed: 6'-98'/min (2-30m/min)
Complete with the Following Components:
Uncoiler with Peeler Hold Down Roll
Shear and End Welder
Vertical Accumulator
Two Sets of Entry Edge Guides
Forming Group
Rofin Laser Welder
De-oxidizing Chamber
XIRIS Weld Monitoring Camera
Polishing Section
Caterpillar Drive
Seam Annealer
Three Roll Sizing Head
Eddy Current Tester
Turks Head
Ink Jet Printer for Labeling Pipe
Rotary Flying Cut Off
End Table
Offline 50 ton Flattening Press for testing
Extra Set of Rafted Stands
Tooling for the following outer diameters: 17mm, 25.4mm, 28.6mm, 35mm, 38.1mm, 42.7mm, 54mm, 57.15mm, 60.5mm
