1600mm x 9mm x 20 Ton Yousung Loop Slitting Line (2002)
1600mm x 9mm x 20 Ton Yousung Loop Slitting Line (2002)
1600mm x 9mm x 20 Ton Yousung Loop Slitting Line (2002)
1600mm x 9mm x 20 Ton Yousung Loop Slitting Line (2002)
1600mm x 9mm x 20 Ton Yousung Loop Slitting Line (2002)
  • 1600mm x 9mm x 20 Ton Yousung Loop Slitting Line (2002)
  • 1600mm x 9mm x 20 Ton Yousung Loop Slitting Line (2002)
  • 1600mm x 9mm x 20 Ton Yousung Loop Slitting Line (2002)
  • 1600mm x 9mm x 20 Ton Yousung Loop Slitting Line (2002)
  • 1600mm x 9mm x 20 Ton Yousung Loop Slitting Line (2002)

1600mm x 9mm x 20 Ton Yousung Loop Slitting Line (2002)

Brand
Not Specified

Model
Not Specified

Type
Slitters & Slitting Lines

Stock #
605166

Condition
Used

Year
2002

Request a Quote
Have one to sell?
Width 63 inches
Thickness 0.354 inches
Coil Weight 40000 pounds

Equipped With

Manufacturer: Yousung (S. Korea)
Year: 2002

Thickness Range: 1.8mm to 9mm
Material: Hot Rolled and Cold Rolled Steel
Speed: 80mpm
Max Strip Width: 1600mm
Max Coil Weight: 20 Ton
Yield strength at 8mm : 36kg/cm2
Number of cuts at 8mm = 5 cuts


Complete Line with the Following Components:

Floor Type Coil Car

Mandrel Uncoiler
Powered Hold Down Roll
Hydraulic Expansion

Peeler Hold Down Roll

Entry Edge Guides

Entry Crop Shear

Slitting Head
Arbor Diameter:  300mm
Slitter 110kw [150HP]

Scrap Winders

Looping Cross Over Table

Exit Crop Shear

Rotary Tension Stand

Recoiler
Full Hydraulic Drum
Overarm Separator
Recoiler 150kw [200HP]

Exit Floor Type Coil Car

Complete with Controls, Hydraulics, Electrics

Installed
