Manufacturer: Bonak
Material Specifications:
Max Coil Width: 1550 mm
Min Coil Width: 250 mm
Max Coil Weight: 30 Tm
Thickness Range: 0.5 to 8.0 mm
Max Speed: 120 meters/minute
Line Direction: Right to Left
Complete Line with the Following Components:
Floor Type Coil Car
Double Expandable Mandrel Uncoiler
Coil ID Max and Min: 2000 mm Max..... min.600 mm
Coil ID Range: Max. 760 mm Min. 508 mm
Powered Hold Down Roll
Hydraulic Expansion
Telescopic Peeler Table
Double Entry Edge Guides
Entry Pinch Roll
5 Roll Bonak Flattener
Slitting Head
Complementary Set of Knives, Rubbers and Spacers
80KW Motor
Scrap Chopper
Exit Crop Shear
Recoiler
Full Hydraulic Drum
Over Arm Separator
110KW Motor Drive
Exit L-Type Coil Car
Complete Line with Electrics, Hydraulics, Controls and Drawings
Installed
